Description
- Finish: Matte
- Adjustable Objective: No
- Side Focus: No
- Reticle Focal Plane: Second Focal Plane
- Elevation Adjustment Type: CDS-ZL
- Zero Stop: Yes
- Locking Dial: Yes
- Revolution Indicator: No
- Rezero Type: Set Screw
- Windage Adjustment Type: Finger Click
- Custom Dial Compatible: Yes
- BDC Dial Included: No
- Reticle: Duplex
- Light Management System: Elite Optical System
- Magnification Type: Variable
- Illuminated: No
- Nightvision Compatible Illumination: No
- Daylight Bright Illumination: No
- Motion Sensor Technology (MST): No
- Electronic Reticle Level: No
- Guard-ion Lens Coating: No
- Weight (oz): 13.5
- Elevation Adjustment Value per Click: 1/4MOA
- Elevation Adjustment Range (MOA): 55
- Elevation Adjustment Range (MIL): 16
- Elevation Adjustment Range (cm @ 100m): 160
- Elevation Adjustment Per Revolution: 15 MOA
- Elevation Dial Travel Limit: 14.5MOA
- Windage Adjustment Value per Click: 1/4MOA
- Windage Adjustment Range (MOA): 55
- Windage Adjustment Range (MIL): 16
- Windage Adjustment Range (cm @ 100m): 160
- Windage Adjustment Per Revolution: 15 MOA
- Magnification Max: 10
- Magnification Min: 3.5
- Objective Lens Diameter (mm): 40
- Linear FOV Low Mag (ft@100yds): 29
- Linear FOV High Mag (ft@100yds): 11
- Angular FOV Low Mag (Degrees): 5.5
- Angular FOV High Mag (Degrees): 2.1
- Eye Relief Low Mag (in): 4.4
- Eye Relief High Mag (in): 3.6
- Fixed Parallax-Free Distance (yd): 150
